Oil Hose With Copper Wire
Product Details:
- Supply Ability : 1 Piece Per Day
X
Price And Quantity
- 1 Piece
Trade Information
- 1 Piece Per Day
- 1 Days
Product Description
Available Sizes: 25 mm to 100 mm I.D.
Pressure at 30°C
- Working Pressure 4kg/cm² to 8kg/cm²
- Bursting Pressure 14kg/cm² to 22kg/cm²
Colour: Blue
SPECIFICATIONS
| Nominal Size | Diameter | Bending Radius | Pressure (at 30°C) | Standard Lengths | |||
| Inches | mm | ID mm | OD mm | mm | Working kg/cm² | Bursting kg/cm² | mtrs. |
| 1 | 25 | 25.4 ± 0.5 | 30.0 ± 1.0 | 48 | 8.0 | 22 | 30 |
| 1¼ | 30 | 31.8 ± 0.5 | 36.8 ± 1.0 | 68 | 7.0 | 21 | 30 |
| 1½ | 40 | 38.0 ± 0.5 | 43.3 ± 1.0 | 70 | 5.5 | 18 | 30/50 |
| 2 | 50 | 50.8 ± 1.5 | 57.8 ± 1.0 | 100 | 4.5 | 18 | 30 |
| 2½ | 65 | 63.5 ± 1.0 | 72.5 ± 1.5 | 120 | 4.5 | 18 | 30 |
| 3 | 75 | 76.2 ± 1.0 | 85.2 ± 1.5 | 155 | 4.5 | 18 | 30 |
| 4 | 100 | 101.2 ± 1.0 | 112.2 ± 1.5 | 213 | 4.0 | 14 | 15/18/30 |
Recommended Maximum working temperature: 60/70°C
